Select the required program by pressing button
Select the required program by rotating the encoder.
Only the memories location occupied by a program
are retrieved, while the empty ones are automatically
skipped.
4
Program cancellation
Enter the "Program cancellation" screen by pressing the
button for at least 1 seconds.
Select the required program by rotating the encoder.
Delete the selected program by pressing button (1)
.
Confirm the operation by pressing button (2)
Confirm the operation by pressing button (1)
Cancel the operation by pressing button (2)
3.6 Interface personalisation
1
7 segment display personalisation
All manuals and user guides at all-guides.com
.
.
.
.
Enter set-up by pressing the encoder button for at least
5 seconds.
Select the required parameter by rotating the encoder
until it is displayed within the central quadrant (5).
Store the selected parameter in the 7 segment display
by pressing button (2)
Save and exit the current screen by pressing button (4)
.
Default I1
3.7 Interface personalisation
Allows the parameters to be customized on the main menu.
500
Allows the selection of the required graphic interface:
XE (Easy Mode)
XA (Advanced Mode)
XP (Professional Mode)
PROCESS
PARAMETER
MMA
XE
TIG DC
TIG AC
MMA
XA
TIG DC
TIG AC
MMA
XP
TIG DC
TIG AC
3.8 Lock/unlock
Allows all the settings to be locked from the control panel with
a security password.
Enter set-up by pressing the encoder key for at least 5 seconds.
Select the required parameter (551) by rotating the encoder
until it is displayed within the central quadrant.
.
37
