Before you start the device
REMOTE CONTROL:
HOW TO INSERT OR CHANGE THE BATTERY
The remote control unit is delivered together with a lit-
hium button cell. To enable the remote control, remove
the plastic tape that protrudes from the battery compart-
ment
(see Figure 1).
13
1
If the remote control battery needs to be replaced, in-
sert a new 3-volt lithium button cell. Pay attention to the
type of lithium button cell (CR2025).
2
Press the tab
on the battery compartment
12
of the remote control toward the centre. Now pull
out the battery compartment
Remove the old battery.
Insert a new 3V-button-cell battery (type CR2025).
Pay attention to the correct polarity.
Push the battery compartment
mote control unit until the tab
32
GB/IE/NI
Hang the device onto the wall. The device's air outlet
screws
Please note: Make sure that the wall can bear
weights of at least 4.1 kg.
1. Drill two holes with a 6 mm drill and insert the sup-
2. Screw the fastening screws
3. The distance between the holes must be 31.5 cm
4. The distance to the ceiling and walls must be at
5. The distance to the floor must be at least 2m (see
Please note: If the specified distances can not be
maintained, the device may not be mounted.
Please note: If necessary, you will need a climbing aid
(e.g. a ladder) to carry out the installation.
13
(see Figure 2).
13
6. Place the heater onto the fastening screws
back into the re-
13
snaps into place.
7. Make sure that the fastening screws
12
8. Now move the heater to the right and then down
Installation
General installation instructions
should be at the bottom Use the dowels
G
included in the delivery.
I
plied wall dowels into them
. Each screw
shall protrude to about 10 mm.
J
I
PLEASE NOTE: When drilling, make sure that you
do not damage concealed power lines!
(see Figure 3).
least 30 cm.
Figure 4).
3
(see Figure 5).
straightly inserted into the holes
to the position
.
and
J
.
J
into the wall dowels
I
I
are
I
(see Figure 6).
