REPLACING THE CARBON FILTERS

A carbon filter cleans the air and filters the smell that occurs during cooking. A carbon filter
4
can not be washed and reused. In all cases it is necessary to replace the carbon filter at
least every four months.
• Remove the grease filters.
• Attach three carbon filters to the grease filters.
• Replace the grease filters.
*
3 CARBON FILTERS for model AKB9004RGT - article number KB93

CHANGING A LED SPOT

When a LED spot of the cooker hood is broken, you can replace it yourself. Follow these steps:
• Unplug the appliance or remove the connector fuse.
• Remove the grease filters and push the complete spot from the inside downwards - figure 1.
• Unplug the broken LED from the transformer - figure 2. Replace the complete LED with a matching type (3.0 W, LED L27A).
• Plug the new LED in the transformer and push the complete spot back in the housing of the cooker hood.
• Replace the grease filters and plug the appliance in.
1
2
6

troubleshooting

What to do in case of a malfunction? In most cases, you will be able to correct these faults easily yourself. Please check the solutions
below before contacting the Inventum service department.
The motor is not running
• Is it plugged in correctly?
• Is there a power outage?
• Check the electrical installation.
The performance of the cooker hood is not correct and makes more nois.
• Is the diameter of the exhaust-air pipe correct?
• Is the duct blocked?
• The diameter of the duct must be 150 mm. A smaller diameter can negatively influence the suction of the motor.
• Are the grease filters clean?
• Are the carbon filters not replaced within the last 6 months? Replace the carbon filters.
• Is there enough air supply to replace the extracted air?
22
English
