Omgevingscondities
Uitvoering
Standaard uitvoering
Uitvoering IP66/IP68 (1 bar)
Uitvoering IP68 (25 bar), aansluitka-
bel PUR
Uitvoering IP68 (25 bar), aansluitka-
bel PE
Elektromechanische gegevens - uitvoering IP66/IP67 en IP66/IP68 (0,2 bar)
Opties voor de kabelinstallatie
Ʋ Kabelinvoer
Ʋ Kabelwartel
Ʋ Blindplug
Ʋ Afsluitkap
Materiaal kabelwartel/afdichtings-
element
PA/NBR
Messing, vernikkeld/NBR
Roestvast staal/NBR
Aderdiameter (veerkrachtklemmen)
Ʋ Massieve ader, litze
Ʋ Litze met adereindhuls
Elektromechanische gegevens - uitvoering IP66/IP68 (1 bar)
Aansluitkabel, mechanische gegevens
Ʋ Constructie
Ʋ Standaard lengte
Ʋ Min. buigradius (bij 25 °C/77 °F)
Ʋ Diameter
Ʋ Kleur - uitvoering PE
Ʋ Kleur - uitvoering PUR
Aansluitkabel, elektrische gegevens
Ʋ Aderdiameter
Ʋ Aderweerstand R
IP66/IP68 (0,2 bar) alleen bij absolute druk.
20)
VEGADIF 85 • 4 ... 20 mA/HART SIL
Omgevingstemperatuur
-40 ... +80 °C (-40 ... +176 °F) -60 ... +80 °C (-76 ... +176 °F)
-20 ... +80 °C (-4 ... +176 °F)
-20 ... +80 °C (-4 ... +176 °F)
-20 ... +60 °C (-4 ... +140 °F)
5 ... 9 mm
´
M20 x 1,5; ½ NPT
M20 x 1,5, ½ NPT (kabel-ø zie tabel onder)
M20 x 1,5; ½ NPT
½ NPT
Kabeldiameter
6 ... 12 mm
●
●
●
●
–
–
0,2 ... 2,5 mm² (AWG 24 ... 14)
0,2 ... 1,5 mm² (AWG 24 ... 16)
Aders, trekontlasting, luchtdrukcompensatiecappilairen,
vlechtwerk, metaalfolie, mantel
5 m (16.4 ft)
25 mm (0.984 in)
ca. 8 mm (0.315 in)
Zwart
Blauw
0,5 mm² (AWG 20)
0,037 Ω/m (0.012 Ω/ft)
Opslag- en transporttemperatuur
-20 ... +80 °C (-4 ... +176 °F)
-20 ... +80 °C (-4 ... +176 °F)
-20 ... +60 °C (-4 ... +140 °F)
20)
7 ... 12 mm
–
–
●
