2 . Installation instructions according collection: Cosivista 120 & 160
The Cosivista is supplied complete with pressure regulator (30 mbar) and gas hose. You only need to purchase a
gas bottle. These can be purchased at your local gas supplier.
1. Installing the Cosivista
Carefully remove your Cosivista from its packaging and select the location for your Cosivista. The location must
meet the following conditions:
-
Make sure that the Cosivista is placed on a paved (preferably stone) surface. The surface should be
completely flat and clean
-
The Cosivista should be placed at least two meters away from flammable materials and liquids. Do you
want to place the Cosivista with the back panel in front of a wall? Always follow the following guidelines:
o
Keep the Cosivista 120 92cm from the center of the burner to each side apart from walls,
furniture and other objects.
o
Keep the Cosivista 160 112 cm from the center of the burner to the left and right side and 92cm
from the center of the burner to the front and back side from walls, furniture and other objects.
-
Lift the top of the Cosivista and place the unpacked Cosi burner in the model. The burner is easier to
position if the control knob is first removed from the burner. Once the burner is put into the recess,
place the control knob back on the burner and guide the gas hose with regulator to the gas tank unit.
Before Cosivista is ready to use you have to place an AAA-battery for the piezo ignition. Please see '2.5 Replacing
the battery for the piezo ignition.'
When the Cosivista is installed properly, you can place the lava rocks and ceramic logs on the top. Every Cosivista
is supplied with small and large lava rocks. Take the small lava rocks without grit and place these gently on the
model. Repeat the process with the big lava rocks and make sure the fire ring is covered with lava rocks. Keep
the space around the ignition unit free of lava rocks and ceramic logs.
After placing the lava rocks, unpack the ceramic logs. The Cosivista 120 & 160 are always supplied with three
pieces. It is recommended to place the ceramic logs as follows:
Make sure the fire ring is only minimally covered by the logs. If the logs block the fire ring, dangerous situations
may occur. The blockade of the fire ring will affect the air flow of the ring and the flames will be different. This
results in dangerous situations! If you want to reorder the lava rocks or ceramic logs, this is possible at your
purchase address.
Pay Attention! When you are going to use the Cosivista for the first time, make sure that the device is turned at
the highest setting for 15 minutes. In this way, the lava rocks are heated through and this ensures that any bumps
or air bubbles will disappear from the lava rocks. During the first time the Cosivista is turned on or when the lava
rocks have been wet (after some rain), keep at least two meters away from the burner and also ensure that no
flammable materials are placed around or on the table within this radius of two meters. Because the air bubbles
are burned from the lava rocks, the rocks can jump up during the first time / when lava rocks have been wet and
possibly come out of the burner.
When you want to move or clean up the lava rocks and ceramic logs, always make sure that they have cooled
down completely.
12
