12. Specificaties
Meetelement
NL
Weerstandssen-
sor
Potentiometer
3)
FLR-sensor
Type thermokoppel
Spanningssensor
1) De zender kan onder deze grenswaarden geconfigureerd worden, maar dit wordt niet aanbevolen vanwege verlies van nauwkeurigheid.
2) Deze modus is niet toegestaan bij de SIL-optie.
3) R
: 1 ... 35 kΩ
total
46
Sensortype
Max. configureerbaar
meetbereik
Pt100
-200 ... +850 °C [-328 ... +1.562 °F]
Pt1000
-200 ... +850 °C [-328 ... +1.562 °F]
CvD
-200 ... +850 °C [-328 ... +1.562 °F]
Pt1000
-260 ... +200 °C [-436 ... +392 °F]
Cryogeen
2)
ontwerp
JPt100
-200 ... +500 °C [-328 ... +932 °F]
JPt1000
-200 ... +500 °C [-328 ... +932 °F]
Ni100
-60 ... +250 °C [-76 ... +482 °F]
Weerstandssen-
0 ... 4.100 Ω
2)
sor
3)
2)
Potentiometer
0 ... 100 %
Reed-keten
0 ... 100 %
J
-210 ... +1.200 °C [-346 ... +2.192 °F]
K
-270 ... +1.300 °C [-454 ... +2.372 °F]
L (DIN)
-200 ... +900 °C [-328 ... +1.652 °F]
L (GOST)
-200 ... +800 °C [-328 ... +1.472 °F]
E
-270 ... +1.000 °C [-454 ... +1.832 °F]
N
-270 ... +1,300 °C [-454 ... + 2,372 °F]
T
-270 ... +400 °C [-454 ... +752 °F]
U
-200 ... +600 °C [-328 ... +1.112 °F]
R
-50 ... +1.768 °C [-58 ... +3.214 °F]
S
-50 ... +1.768 °C [-58 ... +3.214 °F]
B
-50 ... +1.820 °C [-58 ... +3.308 °F]
C
-50 ... +2.315 °C [-58 ... +4.199 °F]
A
-50 ... +2.500 °C [-58 ... +4.532 °F]
2)
mV-sensor
-500 ... +1.000 mV
Standaard
IEC 60751
IEC 60751
n.v.t.
Intern +
IEC 60751
JIS C1606:1989
JIS C1606:1989
DIN 43760:1987
n.v.t.
n.v.t.
n.v.t.
IEC 60584-1
IEC 60584-1
DIN 43710:1985
GOST R 8.585
- 2001
IEC 60584-1
IEC 60584-1
IEC 60584-1
DIN 43710:1985
IEC 60584-1
IEC 60584-1
IEC 60584-1
IEC 60584-1
IEC 60584-1
-
WIKA gebruikshandleiding type T38.x
Min.
meetgebied
1)
(MS)
10 K
20 Ω
10 %
10 %
50 K
150 K
200 K
150 K
10 mV
