Charging the Powerpack
–
The Powerpack is equipped with a capacity indicator, showing the remaining battery
capacity. Also the cooler will show the remaining battery capacity on its display.
–
When the cooler is connected to a 12/24V power supply in a vehicle, or a 110-230V power
supply using the adapter, the Powerpack will be automatically charged.
–
Charging time will be around 4-8 hours, depending on the battery condition, charging
state and available input power.
It is recommended to connect the cooler to a 110-230V power supply, using the adapter,
for charging the battery. The 110-230V adapter will give maximum input power to the
cooler for optimal charging performance. When the cooler is switched off while charging
the battery, the charging time will be decreased while all available power will be used
for charging the battery.
An optional 110-230V battery charger is sold separately to charge the Powerpack without using
the cooler.
WARNING! Do not disassemble the battery. This may result in death or serious
injuries.
8
Advanced Settings
Cooling mode
This cooler is equipped with variable speed compressor technology. The electronics will
automatically vary the compressor speed depending on the conditions to reach and maintain the
set temperature.
MAX mode is the default setting for automatic and quick cooling.
ECO mode will lower the compressor speed and saves up to 35% power consumption. This mode
can also be used at night to reduce unwanted noises.
This feature can be controlled via the app, or changed on the cooler using the control panel:
–
Short press the settings button. The current cooling mode setting will start to flash.
–
Short press the settings button again to switch between modes.
–
After three seconds the selected cooling mode will be set and becomes solid again on
the display .
10
HyCooler Pro Dual zone
Battery protection mode
The intelligent battery protection system will prevent the cooler to drain the vehicle battery.
If the supply voltage falls below a set level, the cooler will switch off. Once the voltage reaches
the restart voltage level, the cooler will automatically switch back on.
The battery protection mode can be set to three levels, following the table below:
12V
OFF
L - Low
8,5V
M - Medium
10,1V
H - High
11,1V
High level should be set when the cooler is connected to a vehicle battery. Medium or
Low level should be set when the cooler is connected to a portable or backup battery.
This feature can be controlled via the app, or changed on the cooler using the control panel:
–
Long press the settings button for three seconds. The current setting will start to flash.
–
Short press the settings button again to switch between modes.
–
After three seconds the selected battery protection mode will be set and becomes solid
again on the display.
Change temperature unit setting
The displayed temperature unit can be changed between °Celsius and °Fahrenheit using this
setting. This affects both the displayed unit in the app and on the cooler.
This feature can be controlled via the app, or changed on the cooler using the control panel:
–
Switch off the cooler.
–
Long press the settings button for five seconds until the display shows 'E1'.
–
Short press the settings button until the display shows 'E5'.
–
Use the + and – buttons to switch between °C and °F.
–
The selected temperature unit will start flashing.
–
After three seconds the display turns off.
–
The selected temperature unit is stored.
Factory reset
In case of any irregularities or recovery of the factory default settings, follow the procedure
below:
–
Switch off the cooler.
–
Long press the settings button for five seconds until the display shows 'E1'.
–
Long press + and – buttons at the same time together for three seconds.
–
A confirmation tone sounds for a successful factory reset.
HyCooler Pro Dual zone
24V
ON
OFF
ON
10,9V
21,3V
22,7V
11,4V
22,3V
23,7V
12,4V
24,3V
25,7V
EN
DE
FR
NL
11
