IN S TA LLA TION M A N U A L
9. Appliance-specific information
•
The appliance-specific instructions as described in this section prevail over the instructions in the other
!CAUTION
sections! If in doubt follow the instructions in section 9 or contact your supplier.
•
The appliance-specific information as described in paragraphs 9.1 to 9.4 applies to all models described in
this manual. Supplementary installation instructions (per appliance) are described in paragraph 9.5.
9.1 Outside air connection, air slide valve and flue gas exhaust
9.1.1 Outside air connection
The fire is made with an outside air connection. This outside air connection is supplied separately.
Assembly always takes place at the bottom of the appliance.
When mounting the outside air connection, please proceed as follows (see Appendix 2, fig. 3):
Ø
Loosen the 4 bolts that are pre-mounted on the outside air connection.
Ø
Bring the outside air connection against the plate on the bottom of the appliance.
Ø
Then re-tighten the 4 bolts.
Ø
Connect the flexible hose (Ø 80 mm) to the round 'pipe opening' of the outside air connection.
The flexible hose can be fed from the back and from the bottom.
In case of a Jannik Large-01, air supply is possible from the back of the appliance.
!Caution
For this purpose see Appendix 2, fig. 3.
9.1.2 Air slide valve
When installing and maintaining the appliance, please check the operation of the air slide valve
(see Appendix 2, fig. 4).
It is possible that steel grit entered the air slide valve during transport. If the air slide valve does not move
smoothly it must be cleaned. For this purpose, the air slide valve must be disassembled. The suspended air slide
valve is spring-mounted using a bolt and a spring, which are located below the cover plate.
When mounting the air slide valve, please proceed as follows (see Appendix 2, fig. 4):
Ø
Remove the vermiculite plates from the bottom (see section 9.2.1).
Ø
Hold the Allen screw at the top of the cover plate stationary using an Allen key, so it will not rotate as well.
Loosen the nut at the bottom at the same time.
As soon as the bolt has been loosened, the air slide valve will fall down. Make sure you catch the air slide valve!
!Caution
Ø
Check the air slide valve and clean it if necessary.
In order to replace the air slide valve, proceed as described for removal, only in reverse order.
37
