Befestigung mit Bohrschrauben / Fixation with self tapping screws /
Fixation par vis autotaraudeuses / Bevestiging met zelfborende
schroeven
66
Alle Maße in mm
All dimensions in mm
Toutes les dimensions sont en mm
Alle afmetingen in mm
XX-INT_Dachanker-TR-fix_MA-220901-1WA20419.
S 5
S 8
21,5
mm
Ø 5,4
S 5
Befestigung mit Nieten / Fixation with rivets / Fixation par rivets /
Bevestiging met klinknagels
min 20
Nur Stahl-Trapezblech / Only steel profile sheets / Bac acier
trapézoïdal uniquement / Alleen staalprofiel platen
t min=0,63
t min=0,50
