Regular Maintenance
!
A
Separator
Remove the two hoses to disconnect the separator from the machine
(Fig.1 & 2).
Remove fixing band holding separator in place (Fig.3).
Lift off the separator. The separator has a sealing-rubber which should
be examined at every clean-down (Fig.4).
Rinse using clean water.
Remove the two filters clipped into the separator and flush with clean water (Fig.A & B).
Replace by fitting the rear of the filter first then clipping the front to lock in place.
ALWAYS ENSURE THAT THE BATTERY IS DISCONNECTED
PRIOR TO ANY MAINTENANCE OPERATION
B
A
4
Emptying Top Tank
After use, empty waste-water tank using
emptying hose and flush-out with clean water.
(fig.A).
Emptying Bottom Tank
The clean-water tank can be drained via the
yellow cap fitted to the left hand side of the
machine. There is a sealing bung beneath the
yellow cap (ensure the sealing bung is clean)
The cap should only be done up by hand.
(fig.B).
1
2
B
T 01460 68600
!
3
17
