period. The instructions about the
Service Centre and conditions of
guarantee are in the guarantee booklet.
8. INSTALLATION
WARNING!
Refer to Safety chapters.
8.1 Before the installation
Before you install the hob, write down
the information bellow from the rating
plate. The rating plate is on the bottom
of the hob.
Serial number ...........................
8.2 Built-in hobs
Only use the built-in hobs after you
assemble the hob into correct built-in
units and work surfaces that align to the
standards.
8.3 Connection cable
• For a single phase or two phase
connection use the following (or
8.5 Assembly
min.
500mm
min.
50mm
higher) mains cable type: H05V2V2-F
T min 90°C.
8.4 Attaching the seal
1. Clean the worktop around the cut
out area.
2. Attach the supplied seal stripe to the
lower edge of the hob along the
outer edge of the glass ceramic. Do
not extend it. Make sure that the
ends of the seal stripe are located in
the middle of one side of the hob.
3. Add some mm when you cut the seal
stripe to the length.
4. Push the two ends of seal stripe
together.
R 5mm
mm 880
+1
490
min.
55mm
ENGLISH
33
+1
mm
