Introduction..................................................................... 2
Safety..............................................................................9
Operation...................................................................... 14
Maintenance................................................................. 27
Troubleshooting............................................................ 39
Product description
The product is a walk behind floor saw with a
combustion engine. The product has an adjustable
pointer that lets you see the operation clearly and makes
it easy to cut straight. The product has a control panel
with a digital display that monitors all functions.
Product overview, left side (FS7000 D)
20
19
Note: The product can have different configurations.
Thus, the appearance of the product can be different
from the product overview.
1. Ambient temperature sensor
2. Air filter
3. Air filter indicator
4. Control panel and display
2
Contents
Introduction
1
19
18
16
17
Transportation, storage and disposal........................... 40
Technical data.............................................................. 44
Accessories.................................................................. 51
EC Declaration of Conformity....................................... 52
Intended use
This product is used with diamond blades for wet cutting
to cut hard floor surface materials such as concrete,
asphalt and stone. All other use is incorrect.
The product is used in industrial operations by operators
with experience.
2
3
15
14
13
5. Water inlet
6. Operation handles
7. Radiator air filter
8. Weight kit
9. Type plate for EU
10. Locking knob for operation handles, adjustment in
length
11. Rear tie-down bracket
21
4
5
6
7
8
9
10
11
12
1223 - 002 - 09.07.2019
