GB - SuperFish Pond Clear 24000 Filter + UVC
Biological 2-chamber pond filter with built-in UVC for Koi and fish ponds up to 24,000 litres. Filters
and clarifies pond water at the same time, ensuring quick results and optimal purification of the water.
Safety
• Suitable for outdoor usage.
• Read this manual carefully before usage.
• The built-in UVC device produces harmful radiation, direct contact may be dangerous for eyes and skin.
• Never look at a burning UV lamp, switch of the power before any maintenance or opening the unit.
• Ensure voltage shown on the label match to the mains supply voltage.
• This filter should be only used for cleaning pond water and the water temperature should not exceed 35°C. It should never be
used for other liquids or chemicals.
• The Pond Clear plug may only be connected to an earthed wall socket. Ensure that water cannot reach the socket (A).
• Take great care using electricity in combination with water, do not operate with wet hands or plug is wet. Never operate the
filter if there are people in the water.
• In the event of damage to the unit, cord or plug, do not use the unit and return the unit to your dealer for repair or recycling.
• Do not use this unit if any parts are damaged, especially the quarts glass, buy new parts at your dealer.
• Unplug or switch off all appliances in the pond before carrying out maintenance.
• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been given supervision or instructions concerning the use of the
appliance in a safe way and understand the hazards involved. Children may not play with the appliance. Cleaning and user
maintenance shall not be done by children without supervision.
Installation
(see pictures on page 2)
• The filter should be installed close to the pond and it should be easily accessible for maintenance (B).
• The filter inlet must be higher than the water level in the pond, preventing the filter to overflow.
• Cut hose connection on the same diameter as the diameter of the hose (B). Then screw the hose connection on to the filter
cover.
• Connect the pond pump to the filter inlet, using a pond hose and hose clamps (C).
• Put filter outlet above the pond, if needed fit a pipe to lengthen the filter outlet. The horizontal pipe of this outlet should not be
longer then 1 metre to avoid pressure in the outlet (D). Never block or reduce the outlet diameter, otherwise the filter may
overflow and your pond could get empty.
• Install and operate the pump and check the system for leakage, make sure all connections are 100% waterproof. Leakage may
lead to an empty pond and cause harm to your fish and plants.
• Check the water level in the filter and make sure it cannot overflow.
• Check the operation of the UV lamp via the peephole on the side of the filter cover (E).
• You can add extra biological filter media (eg. Active carbon, Bio-Balls, Zeolite) in the filter trays or in the middle of the filter
cassettes. Put this filter media into a handy filter media bag.
E
Filter maintenance
• Always disconnect from the mains supply before carrying out any maintenance! Turn off the filter pump and deflate the filter.
• Regularly clean the filter. Upon initial installation or if your pond is heavily polluted, it may be necessary to clean the filter foam
daily.
• Replace the filter sponge yearly (Art. 06020221 Pond Clear 24000 Replace sponge).
• Any biological filter media (eg. Bio-Balls, Zeolite) should be cleaned twice a year in a bucket filled with pond water. Do not use tap
water for this purpose!
• Clean the filter foam alternately, one time the filter cassette (Fa) from the first chamber, the other time from the second
chamber (Fb). Rinse the filter foam at least once a month with tap water.
• Remove the filter cassette from the filter, push the locks on the top of the cassette to the inside to unlock (G).
4
F
a
G
b
