Installatiehandleiding
DHR - classic DHR - comfort DHR - expert
7

Technische gegevens

7.1

Algemeen

Bedrijfsspanning
Opgenomen vermogen
Omgevingstemperatuur bedrijf
Omgevingstemperatuur opslag/transport
Vochtigheid in bedrijf
Voelerbekabeling, lengte, Doorsnede
eBUS
Busbekabeling, lengte, doorsnede:
Belastbaarheid:
Schakelvermogen uitgangen electro- mecha-
nisch (Relais)
Regelwaarde-ingang
Normeringen
Beschermingsklasse
Afdichtingsnorm bij correcte inbouw
EMV
EMC-Emissie
Gangreserve klok
Dok. Nr. 112652 36/2010
230 VAC + 10 %, 50 Hz
max. 10 VA
0 °C ... 50 °C
-20 °C ... 60 °C
max. 85 %; niet condenserend
max. 100 m; min. 0,75 mm
2-Draadsbus, twisted pair, max. 50m, min. 0,5mm
DHR - classic /- comfort max. 15 mA (constant)
DHR - expert max. 27 mA (constant)
230 V 6 (2) A, 50 Hz
0-10 V = 0-100 °C; niet potentiaal vrij; Stroom max.
1 mA
De regelaar is
-conform overeenkomstig de
navolgende richtlijnen:
• 73/23/EWG "Laagspanningsrichtlijn"
• 89/336/EWG "EMC-Richtlijn", inclusief gewij-
zigde richtlijnen tot 93/86/EWG73/23/EWG
II
EN 60730
IP 40
EN 60529
EN 50082-1
EN 50081-1
DHR - classic /- comfort = 24 h
DHR - expert = max. 2 Jaar
2
2
37
