2.2. Maatgegevens QB1-10 XE / QB1-21 XE
│
Omschrijving
Vuilwaterbuis
Buitenbuis
Aansluiting tot
aansluiting h-o-h
Beugel tot beugel
Aansluiting tot Beugel
Min. Benodigde
inbouwhoogte
2.3. Technische gegevens
Omschrijving
Lengte
Inhoud sanitair water
Afvalwater aansluiting
Sanitair water aansluiting
(inw.)
Max. aanhaalmoment
Maximale werkdruk
Max. watertemperatuur
Rendement bij 5,8 l/min
Rendement bij 9,2 l/min
Rendement bij 12,5 l/min
Drukverlies bij 5,8 l/min
Drukverlies 9,2 l/min
Drukverlies 12,5 l/min
Letter
Eenheid
A
mm
B
mm
C
mm
D
mm
E
mm
mm
Eenheid
mm
Liter
mm
-
Nm
bar
°C
%
%
%
bar
bar
bar
QB1-10 XE
QB1-21 XE
1050
1010
920
700
Ca. 100
1300
QB1-10 XE
QB1-21 XE
1050
0,26
50
G1/2´´
50
8
60
53,8
49,0
45,3
0,11
0,25
0,42
2100
2060
1970
1400
Ca. 250
2350
2100
0,53
50
G1/2´´
50
8
60
70,5
66,3
62,8
0,14
0,31
0,53
