8. INSTALLATION
8.1 Before the installation
Before you install the hob, write down the
information bellow from the rating plate.
The rating plate is on the bottom of the
hob.
Model .......................................
PNC .........................................
Serial number ...........................
8.2 Built-in hobs
Only use the built-in hobs after you
assemble the hob into correct built-in units
and work surfaces that align to the
standards.
8.3 Connection cable
• The hob is supplied with a connection
cable.
8.5 Assembly
WARNING!
Refer to Safety chapters.
min.
500mm
• Replace the damaged mains cable with
8.4 Attaching the seal
1. Clean the worktop around the cut out
2. Attach the supplied seal stripe to the
3. Add some mm when you cut the seal
4. Push the two ends of seal stripe
min.
50mm
min.
55mm
a special cable (type H05BB-F Tmax
90°C; or higher). Speak to your local
Service Centre.
area.
lower edge of the hob along the outer
edge of the glass ceramic. Do not
extend it. Make sure that the ends of
the seal stripe are located in the
middle of one side of the hob.
stripe to the length.
together.
R 5mm
+1
490
mm
+1
270
mm
