2.0 Safety
Follow the instructions carefully next to these warning symbols! Not paying
careful attention to these instructions could result in physical injury or
damage to the wheelchair or the environment. Where ver possible, safety
information is provided in the relevant chapter.
2.1 Symbols and labels used on the product
The signs, symbols and instructions affixed to the wheelchair comprise part
of the safety facilities. They must never be covered or removed. They must
remain present and clearly legible throughout the entire lifespan of the
wheelchair.
Replace or repair all illegible or damaged signs, symbols and instructions
immediately. Please contact your dealer for assistance.
Fig. 2.1. WARNING - Do Not Touch - HOT
Fig. 2.2. Taxi fixation point
Fig. 2.3. WARNING – Danger of finger entrapment
Fig. 2.4. WARNING – Ensure that the seat interface quick release is screwed
in tight before using your wheelchair, especially on a slope
Fig. 2.5. WARNING – Do not drive your wheelchair on a slope with the
backrest reclined and/or the seating in standing mode
Fig. 2.6. WARNING – Maximum user weight for the wheelchair: 136 kg
Fig. 2.7. Warning - Do not operate in C-Me mode on slopes.
Fig. 2.8. Freewheel mechanism: outward lever down = freewheel
Fig. 2.9. UK Responsible Person label (example only).
Fig. 2.10. The serial number and information label, (example only).
Fig. 2.11. Location of Serial Number Label, (overleaf - Fig. 2.11.1 Mid wheel,
Fig. 2.11.2 Front Wheel, 2.11.3 Rear Wheel).
2.2 Safety: Temperature
WARNING!
• Avoid physical contact with the wheelchair's motors at all times. Motors
are continuously in motion during use and can reach high temperatures.
After use, the motors will cool down slowly. Physical contact could cause
burns. Allow the motors after using at least 30 min. to cool down.
• If you do not use the wheelchair, ensure that it is not exposed to direct
sunlight for lengthy periods of time. Certain parts of the wheelchair, such
as the seat, the back and the armrests can become hot if they have been
exposed to full sunlight for too long. This may cause burns or allergic
reactions to the skin.
Sunrise Medical GmbH
Kahlbachring 2-4
D-69254 Malsch / Germany
POWER WHEELCHAIR
TYPE:
Q400 M
FIN-Nr:
ISO 7176-19:2008
max
max
max
max
kg
kg
kg
136 kg
385 kg
6 km/h
max 6°
60 kg/250 kg/100 kg
6
Sunrise Medical GmbH
2021-05-04
Kahlbachring 2-4
D-69254 Malsch / Germany
203211733451938
POWER WHEELCHAIR
TYPE:
4M2145387
Q400 F
ISO 7176-19:2008
max
max
kg
kg
136 kg
350 kg
10 km/h
136 kg
R
2021-04-15
230211533148115
TYPE:
Q400 R
FIN-Nr:
4F2145908
max
max
kg
kg
136 kg
max 6°
100/280 kg
Fig. 2.2
Fig. 2.4
Fig. 2.6
MAX
Sunrise Medical Limited
Thorns Road, Brierley Hill
West Midlands, DY5 2LD
UNITED KINGDOM
Sunrise Medical GmbH
Kahlbachring 2-4
D-69254 Malsch / Germany
230211533148085
POWER WHEELCHAIR
FIN-Nr:
4R2148117
ISO 7176-19:2008
max
max
max
max
kg
kg
385 kg
6 km/h
max 6°
240/190 kg
Q400 M/F/R | Rev. J | English
Fig. 2.1
Fig. 2.3
Fig. 2.5
Fig. 2.7
Fig. 2.8
Fig. 2.9
2021-04-19
Fig. 2.10
