THERMO TRANSMITTER
15
(15) Thermo transmitter
(16) Status LED thermo transmitter
(17) Learn button thermo transmitter
(18) Connection thermo transmitter
(19) Battery compartment 3 x AA
T = Thermal sensor
B = Mounting bracket
(a) Holes for screws
(b) Hole for thermal sensor
24
AS 7000_1.Vers. 2017 Manual 3xAA@150x180.indd 24
19
Flue pipe
16
17
18
Distance to
the fireplace
minimum
50 cm!
T
B
a
b
(Figure 3)
