Fitting the brushes
Featuring the Nulock brush system.
The brush is simply pushed and twisted to lock, making fitting and removal a simple process.
The Pad is retained using Numatic's own PadLoc system (ask your supplier for details).
Only use manufacturer supplied brushes / pads.
TTB 4045 / ETB 4045 requires a 450mm brush or a 400mm pad.
TTB 4055 requires a 550mm brush or a 500mm pad.
Safety gloves are recommended for the changing of used brushes.
Tipping the Brush Deck
ALWAYS ENSURE THAT THE BATTERY IS DISCONNECTED
BEFORE MAKING ANY ADJUSTMENTS
Fit the brush / pad to the drive chuck,
twist to lock the brush
(Fig.14) / pad in place (Fig.15).
Fig.14
To tip the deck into the down position (Operating mode) press in the brush
deck locking bar (Fig.16) and rotate the brush deck (Fig.17).
Fig.16
To change to brush deck up position, (Transit mode) simply lift the deck
and the sprung loaded locking bar will active to hold the deck up.
Fig.17
24
Machine Set-Up
Fig.15
!
