Warranty
The product warranty is pursuant to the Danish Sale of Goods Act.The warranty period starts on the day
the product was purchased.
Warranty handling
A defective product must be returned to the place of purchase along with a valid receipt. If the product
becomes defective during the warranty period, the product must be returned to the place of purchase.
Warranty disclaimer
Damage or defects resulting from neglect or improper use of the product is not covered by the warranty.
The warranty does not cover force majeure such as lightning, flood, fire or damage occurred during
transport. Warranty cover will be void, if the product's serial number has been changed, if any modifications
have been made or if a repair has been attempted by any unauthorized service centre.
Product specifications
Model no.
ZHQ2090-C-RMLED
Art. No.
Power source
Consumption
Protection class
OPERATING INSTRUCTIONS
1.
Place the heater on a firm, level ceiling surface.
2.
The hook on the ceiling hanging the patio heater
must be able to undertake a weight 3 or 4 times that
of the patio heater itself.
3.
The distance between the bottoms of the Patio
heater to the Floor must be over 1.8 meter (fig. 1).
4.
Plug the Patio Heater into a grounded 230V ~ 50Hz
power outlet.
5.
The switch on the heater head is used to control the
power. (I) position for turn on. (0) position for turn
OFF (fig. 2).
6.
Activating button on the heater is to operate heater
by manually (fig. 3).
Press one time for 1000 W,
Press again for 2000W (1000W+1000W),
Press third times for turning on two LED light with-
out heat,
Press four times for turning on the two LED light and
heater (for 2000W)
Press five times for turn off the LED light and heater.
7.
Only operate the heater when it is in hanging posi-
tion.
211-309
230V AC ~ 50 Hz
1000/2000w
IP65
Ceilling
min.
min.
min.
Floor
fig. 1
fig. 2
REMOTE CONTROL
min.
min.
Wall
fig. 3
