Piezo ignition
Z4
Knob
Burner
1+2
Main burners
3+4
High-power burners
5
Side burner
Icon
Meaning
Big flame
Small flame
1. Rotate all knobs to the OFF position.
2. Open the valve on the gas bottle.
3. Press and hold the knob (1). Rotate the knob to
the left up to the position. The ignition occurs
automatically. A clicking sound indicates that
the product is igniting. If the flame does not
burn upon the first try, repeat the process 4 to
5 times until the flame is burning.
4. Optional: Proceed as described above to
ignite the other burners with knobs (2), (3),
(4) and (5).
5. Set the desired temperature according to the
scales on the knobs.
INFO: Allow the product to pre-heat for
approx. 15 minutes before adding food to
achieve better cooking results.
10 GB/IE/NI
[
]
[
]
Burn-in technique
DANGER! Risk of fire! Risk of injuries!
m
Risk of burns!
Do not spray the oil directly onto the main
burners, the high-power burners and the side
burner
.
[
]
Do not leave the product unattended at all
times during the burn-in process. Switch off all
burners and let the product cool down before
leaving the product.
INFO:
Carry out the burn-in technique to clean the
internal parts and to burn off any residues
caused by manufacturing.
Use heat-resistant oil (e.g. canola oil or
sunflower oil).
1. Remove the following parts from the product
(Fig. Z3):
–
Warming rack
2 ]
[
–
Flame diffusers
[
3 ]
–
High-power burner flame diffusers
–
Grate
[
9 ]
–
Cast iron grill grate
–
Grate with grill-in-grill system
2. Spray the inside of the product with oil. It is
important to spray the internal area of the
burner housing with lid
3. Wipe the inside of the product with a cloth
or towel on all the places where the oil has
been sprayed. Thoroughly wiping the oil into
the product is important to make sure the oil is
spread around the whole area.
4. Spray the following parts with oil:
–
Warming rack
2 ]
[
–
Flame diffusers
3 ]
[
–
High-power burner flame diffusers
–
Grate
9 ]
[
–
Cast iron grill grate
–
Grate with grill-in-grill system
Thoroughly rub the oil into the components.
5. Reinsert the components from step 1
back into the product. Close the
4 ]
[
[
9 ]
[
]
[
]
burner housing's lid
6. Open the lid
. Slowly switch on one burner
1 ]
[
to a low setting.
[
4 ]
[
]
[
]
(Fig. Z3).
1 ]
[
[
4 ]
[
]
[
]
2 ]
[
3 ]
[
.
[
1 ]
