inverter.
This warranty is void if the inverter has suffered any physical damage or alteration, either internally
or externally, and does not cover damage arising from improper use, attempting to operate the
inverter with excessive power consumption requirements, or from use in an unsuitable
environment.
This warranty will not apply where the product has been misused, neglected, improperly installed
or repaired by anyone other than Alessi Center. Alessi Center is not responsible for any loss,
damage or costs arising from improper use, use in an unsuitable environment, improper installing
of the inverter and inverter malfunctioning.
5. MAINTENANCE / FUSE REPLACEMENT
5.1
Maintenance
Your Alessi inverter does not need any specific maintenance besides checking all DC and AC
connections at least once a year. Check if all nuts and bolds in the electrical system are still
tightened sufficiently and if all cables are in good condition. Keep the inverter reasonably clean and
remove eventual dust/cloth gathered at the fan in- and outlets to avoid extra airflow obstruction.
5.2
Replacing fuses
The inverter is equipped with two internal fuses, one on the DC side and one on the AC side.
These fuses will only blow in case of serious malfunction and/or external inverter abuse like
reverse polarity of battery connections. Both fuses can be accessed by removing the hood of the
enclosure as described below.
BEFORE OPENING THE INVERTER TO REPLACE A FUSE, ALWAYS
DISCONNECT THE BATTERY FROM THE INVERTER FOLLOWED BY
DISCHARGING THE INTERNAL CAPACITORS BY PUSHING THE POWER
SWITCH (OF THE DISCONNECTED INVERTER) IN THE 'I' POSITION FOR 10
SECONDS.
CAUTION
1. Unscrew the 8 top hood screws (4 on each side, see picture below) to lift the top hood, enabling
access to the internal fuses. To make removing the top hood easier, it is advisable to slightly
unscrew the remaining left- and right screws on one side of the inverter.
Remove these four screws on both
sides of the inverter enclosure
The Alessi-Serie
Pure Sine Wave Inverters
1
- 13 -
Gently lift the hood upwards
2
