4. AFMETINGEN
HRDF1 - 030 / 050 / 070
A (mm)
HRDF1-030
1188
HRDF1-050
1432
HRDF1-070
1646
6
6
ver.1 31-05-21
ver.1 31-05-21
O (mm)
B (mm)
C (mm)
D (mm)
1135,5
797
281,5
30,5
1347,5
885
322,5
30,5
1547,5
1065
364,5
30,5
2VV. Creating innovative solutions for you and your business since 1995.
2VV. Creating innovative solutions for you and your business since 1995.
E (mm)
F (mm)
G (mm)
H (mm)
10
1160
652
Ø8
10
1380
702
Ø8
10
1580
902
Ø8
I (mm)
J (mm)
K (mm)
L (mm)
Ø160
355,5
171
139
Ø200
400,5
195
157
Ø250
508
228
180
M (mm)
N (mm)
403
242
517
285
619
326
