Mobile unit E 327/1 for surgical instruments
,
Please read the Warning and Safety instructions in the Operating Instructions for your washer-disinfector carefully. You should only process instruments/medical
products in this mobile unit if they have been declared as suitable for machine processing by the manufacturer. Please also observe the manufacturer's care
instructions. The programme selected must be suitable for the materials from which the medical products to be processed are made. Where possible the programme
should include thermal disinfection. The final rinse should, if possible, always be carried out with fully de-mineralised water.
If using automatic mobile unit recognition please make sure that the coding is correctly set.
Items supplied:
Mobile unit E 327/1 with 2 levels, H 502, W 535, D 515 mm, with a holder for the magnetic strip used in automatic mobile unit recognition (G 7835, G 7836, PG 8535 and
PG 8536) and spray arm magnets used for spray arm monitoring (PG 8535 and PG 8536 only).
Accessories available to order:
– Magnet strip ML/2 for automatic mobile unit recognition
– E 142 DIN mesh tray
– E 476 holders for micro instruments
– E 473 insert for very small items
^ Hinged instruments must be opened
up before being placed in the mesh
trays to minimise the risk of surfaces
not being accessed during
processing.
Miele Company Ltd., Fairacres, Marcham Road, Abingdon, Oxon, OX14 1TW, Tel 0330 160 6600,
Internet: http://www.miele.co.uk / ! 0297
^ To prevent the risk of light
instruments such as bulldog clips
and other small items being moved
about during processing, silicone
holders e.g. E 473 and closable
inserts e.g. E 476 can be used to
keep them secure.
Alteration rights reserved / Publication date 2015-11-01
Areas of application:
The E 327/1 mobile unit is suitable for use in the following washer-disinfectors:
G 7882, G 7882 CD, G 7892, G 7835, PG 8535, G 7836 and PG 8536.
It enables surgical instruments to be cleaned and disinfected in 4 DIN mesh trays.
2 DIN mesh trays can be accommodated on each level.
Loading height (levels numbered from the bottom upwards) [H x W x D in mm]
Level 1
Level 2
Before loading the machine and before starting a programme please check:
– that the spray arms rotate freely,
– that the spray arm jets are clean and free of any blockages,
– that the mobile unit is correctly fitted into the cabinet and that it has connected
correctly with the water intake.
For validation purposes please make sure that you follow the loading
instructions given on the template.
^ Containers e.g. beakers and kidney
dishes should be placed in the
mobile unit, preferably on the top
level, with the open side facing
downwards, ensuring that all
surfaces can be accessed easily
and that cleaning solution can flow
freely off them. They must also be
secure so that they cannot be
flipped over by the force of water
during processing.
If hollow items are placed such that
cleaning solution can collect in
recesses etc. they will not get
properly clean and rinsing results
will be impaired.
112 x 520 x 510
105 x 512 x 480
Access port for wash pressure
measurements, e.g. within context of
performance testing and validation in
accordance with DIN ISO 15883.
^ To carry out wash pressure
measurements, exchange the screw
stopper for a Luer lock adapter, e.g.
E 447.
,
Under no circumstances may the
access port be used to connect
instruments, spray rails, etc.
M.-Nr. 10 337 670 / 00
en
