Trailer tester Item number 10181
Overview
1. Intended use
3. Speci cations
5. Operating instructions
7. Notes for environmental protection
WARNING
Read the operating instructions through carefully prior to initial use and observe all of the safety notes!
Not observing such may lead to personal injury, damages to the device or your property!
Store the original packaging, the receipt and these instructions so that they may be consulted at a later date! When
passing on the product, please include these operating instructions as well.
Please check the contents of package for integrity and completeness prior to use!
1. Intended use
The trailer tester is designed to test the 12 V lighting systems on trailers and caravans with 7-pin plugs without them being connected to the
towing vehicle. And also to test the functionality of the 7-pin trailer socket on the car.
2. Scope of delivery
• Trailer tester
3. Speci cations
Voltage: 12 V DC
Plug:
7-pin
Socket: 7-pin
4. Safety notes
• Keep children away and do not permit children to use this device!
• Only use this product for the intended use!
• Do not manipulate or disassemble the device!
• For your own safety, only use accessories or replacement parts speci ed in the instructions or that the manufacturer
has recommended!
5. Operating instructions
Inserting the battery: The battery compartment is located on the rear of the device. Open the battery compartment by sliding the lid to the side
in the direction of the arrow. When inserting the battery, pay attention to the correct poling, labels for plus and minus poles are at the bottom of
the battery compartment. Place the battery over the fabric tape, this makes it easier to remove the used batteries at a later date. Close the battery
compartment again.
Test the trailer socket of the towing vehicle: Switch o the ignition of the towing vehicle. Insert the trailer tester with the plug side up into
the trailer socket of the towing vehicle. Ask a second person to help you to read o the control lamps of the trailer tester. Switch on at the ignition
and switch the following lighting functions on. If the trailer socket is functioning correctly, the appropriate control lamp of the trailer tester will
light up.
Light function
Left indicator
Right indicator
Dipped headlights
Fog lights
Brake light
2. Scope of delivery
4. Safety notes
6. Care and maintenance
8. Contact information
• Operating instructions
Dimensions (L x W x H):
Weight (with battery):
Batterietyp:
Control lamp on trailer tester
1
4
5 and 7
5, 7, and 2
6
ca.18 x 5,5 x 4,5 [cm]
approx. 0.210 kg
9 V – Blockbatterie, 6F22 (not included)
3
