HOW THE ROBOT WORKS
The robot has a water-propelling nozzle at the bottom of the swivel head. Water is first sucked in through the suction mouth
at the bottom of the robot, which then goes through the filter and is discharged via the propelling nozzle. Water jetting from the
nozzle propels the robot forward. Once the robot stops against an obstacle such as the pool wall, its side flap sways and its
swivel head turns 180˚, allowing the robot to move in the opposite direction. The robot moves in a generally straight pattern in
one direction and in an arc pattern in the other direction. The robot vacuums the pool bottom as it moves, collecting debris in
its compartment.
GETTING STARTED
Charging The Battery
IMPORTANT NOTE: Fully charge the robot ( about 6 hrs ) before using it for the first time.
WARNING!
• Use only the original external adaptor and charging cable provided.
• Make sure the robot and the charging port are clean and dry before set-up and charging.
( TIPS: Pry open the protective cover and use a cotton bud to dry the charging port and charging pins )
• The charging pins are waterproof. However, remnants of water in the port and around the pins could
result in natural occurrence of stains ( a byproduct of chemical reaction between water and electric
currents ). Otherwise, the stains can be removed by light scrubbing with a cotton bud soaked with
juice of lemon or vinegar.
• Make sure the robot is off by sliding the switch to the OFF position prior to charging.
1. Place the unit on a flat surface. Slide the switch to the OFF position.
2. Plug the charging cable of the external adaptor into the charging cable. Pry open the protective
cap. Align and insert the plug of the charging cable into the charging port at the top of the unit.
WARNING! Be sure not to invert the charging cable and ensure both the charging cable and
charging port are clean and dry before charging them. TIPS: Use cotton bud to dry the charging
port and pins.
3. Connect the external adaptor to the power source. The indicator light on the external adaptor turns
red once the charging begins. The indicator light on the external adaptor will turn green when the
robot is charged.
bwt.com
MAINTENANCE & CLEANING
OFF
ON
5-6h
RED light - Charging
GREEN light - Charged
2021/10 : A
3/147
