A
B
C
D
Ref.
Description
A
Handle
B
Display
C
Rotating/pressing knob
D
Main switch (on/off)
2
Device setup
EN
E
F
G
H
I
J
K
L
M
N
O
H
P
Ref.
Description
E
Handle securing screw
F
Vacuum controller VC 10 stand hole
G
Stand securing screw
H
Fan / ventilation slit
I
Hose connection for suction line d= 8 mm (INLET)
J
Accessory fastening (emission condenser)
K
Connection for vacuum controller VC 10 (Mini DIN)
L
USB interface
M
RS 232 interface
N
Water valve connection
O
Hose connection for pressure line d= 8 mm (OUTLET)
P
Power supply cable connection
Fig. 1
