Product Safety Information
Intended Use:
These Air Impact Wrenches are designed to remove and install threaded fasteners.
For additional information refer to Air Impact Wrenches Product Safety Information
Manual Form 04580916.
Manuals can be downloaded from www.irtools.com.
Power Management System
For models that include a power management system, the system allows operator
reduction of maximum output power in either the forward or the reverse direction.
For reduced power in the forward direction and full power in the reverse direction,
push the reverse valve inward on the right side of the tool and rotate the reverse valve until
the notch on the right side aligns with the desired number on the right side. This provides
reduced power in forward but full power in reverse when the reverse valve is pushed in the
opposite direction. (See TPD1248 on page 2.) For reduced power in the reverse
direction and full power in the forward direction, push the reverse valve inward on the
left side of the tool and rotate the reverse valve until the notch on the left side aligns with the
desired number on the left side. This provides full power in forward but reduced power in
reverse when the reverse valve is pushed the opposite direction. (See TPD1249 on
page 2.) For full power in both directions, rotate the Reverse Valve until the notch on
each end of the Reverse Valve aligns with 5 on each side of the housing.
The power level indicators (See TPD1248 and TPD 1249) are for reference and DO NOT
indicate a specific power. The power output can be further reduced in forward or reverse by
using the variable throttle.
Product Specifications
Model(s)
Style
211
Straight
212
Pistol
Model(s)
211
212
04584736_ed3
Drive
Impacts
per min.
Type
Size
Square
3/8"
Square
3/8"
Sound Level dB (A)
(ANSI S5.1-1971)
Pressure
104
97.5
Recommended
Torque Range
Forward
ft-lb (Nm)
1,500
20-125 (27-170) 20-125 (27-170)
1,500
20-125 (27-170) 20-125 (27-170)
Power
(ISO3744)
117
110.5
EN
Reverse
ft-lb (Nm)
Vibration Level
(ISO8662)
m/s²
4.2
2.7
EN-1
