Rear Panel Connections and Controls PA410
VOLTAGE SELECT
Ensure that the voltage
selected matches the local
power supply.
POWER INLET
SUPPLY
VOLTAGE
SWITCH POSITIONS
110-120V/220-240V ~ 50/60Hz
115 = 110 - 120V ~
500W MAX
230 = 220 - 240V ~
POWER INLET
Connect the correct mains cable
here.
The PA410 is designed to run warm in normal use, however
extended use at high volume levels can result in the
ampli er casework becoming hot to the touch.
RS232
This connection allows for remote control
from a third-party home automation
system or computer.
For software upgrades only. See
See "Network and RS232" on page EN-10.
"USB" on page EN-10.
TRIGGER IN
RS232
USB
5V
100mA
TRIGGER OUT
(12V
100mA)
Trigger IN allows the PA410 to be turned on or o by an external source.
USB
Trigger OUT allows the PA410 to control the power state of other connected
IN4
IN3
IN2
IN1
OUT4
OUT3
OUT2
OUT1
PRE-AMPLIFIER INPUTS
Connect the phono outputs of your
pre-ampli er.
See "Connecting Sources and
Loudspeakers" on page EN-13.
PRE-AMPLIFIER OUTPUT
OUT1 to OUT4 provide a copy
of the signal applied to the
IN1 to IN4 phono sockets.
Note: This is a passive output,
no additional ltering or
ampli cation is applied.
EN-9
TRIGGER IN / OUT
equipment
See "Trigger IN/OUT" on page EN-10.
CH4
CH3
CH2
CH1
CLASS 2 WIRING
4-16 OHMS
SPEAKER TERMINALS
See "Connecting Sources
and Loudspeakers" on
page EN-13.
Please read the sections "Placing The Unit",
"Power" and "Interconnect Cables" on page
EN-6
before
connecting
ampli er!
EN
your
PA410
