10
removing the top panel
To install the freezer beneath a counter top for example, you
can easily remove the top panel.
Note: unplug the appliance.
• Remove the screws at the back, holding the top panel to
the appliance.
ble
• Lift the top panel at the backside and remove it.
• Remove the screws on both the frame and the metal
hinge.
• Remove the hinge and the frame. Hold the door tight to
the appliance.
e
• Reassemble the metal hinge using the three screws.
VR551 & VR601 - instructions 0314.indd 19
• Leave the appliance to stand for at least 3 hours before
you insert the plug into the socket.
11
technical specifications
Model
External dimensions
Energy rate
Climat class
Freezer compartment
Number of drawers
Net capacity freezer compartment
Voltage
Wattage
Net weight
Model
External dimensions
Energy rate
Climat class
Freezer compartment
Number of drawers
Net capacity freezer compartment
Voltage
Wattage
Net weight
Note: On the rating label - which you can find at the back on the
freezer - you can also find the technical specificactions.
VR551
55 x 58 x 85 cm
A+
N
****
4
85 liter
230Volt ~50Hz
80 Watt
± 32 kg
VR601
60 x 60 x 85 cm
A++
N
****
3
93 liter
230Volt ~50Hz
80 Watt
± 38 kg
19
English
•
17-03-14 11:43:43
