The hob
Explanation
1
High output burner (3.0 kW)
2
Wok burner (3.9 kW)
3
Standard burner (1.8 kW)
4
Steam outlet
5
Economy burner (1.0 kW)
Types of gas burner
Gas burner
Pot/pan diameter
Economy burner 12 - 14 cm
Standard burner 16 - 24 cm
High output
18 - 26 cm
burner
Wok burner
18 - 26 cm
Control knob for hotplates
This control knob is used to adjust the heat setting of the gas
burner hotplates.
The symbols above the control knob show you the gas burner
to which the control knob belongs.
Setting
Meaning
Û
Off
—
Large flame, highest power
˜
Economy flame, lowest power
Accessories
Accessories
Description
Espresso attachment
Attachment for an espresso pot, for placing
on the economy burner.
Wok attachment
Attachment for a wok, for placing on the
wok burner.
When using the wok attachment, it is possi-
ble to use cooking containers with a diame-
ter greater than 26 cm (woks, frying pans,
pots, containers with a curved base, etc.).
All manuals and user guides at all-guides.com
:
Steam outlet
Hot air from the oven escapes out of the steam outlet on the
hob. Never touch the steam outlet.
Please note that, in the case of appliances with a hob cover,
the burners in the oven may also only be switched on if the hob
cover is open.
The oven
In order to operate the oven, you require two operating knobs:
The function selector and the temperature selector.
Control knob for oven
Function selector
Set the operating mode using the function selector.
Symbol
%
$
*
(
7
2
:
B
Temperature selector
Set the temperature using the temperature selector.
Setting
Û
50 - 260
There is a limit stop between settings 260 and
the knob beyond this point.
Accessories
The accessories can be inserted into the cooking compartment
at 4 different levels. Always insert them as far as they will go so
that the accessories do not touch the door panel. Ensure that
the accessories have always been inserted into the cooking
compartment correctly.
You can pull out the accessories two thirds of the way without
them tipping. This allows dishes to be removed easily.
The accessories may become deformed when they become
hot. As soon as they have cooled down, the deformation
disappears with no effect on the function.
Risk of burns!
Meaning
Top/bottom heating
Bottom heating
Grill
Full-surface grill
Hot air grilling
Top/bottom heating and hot air
Hot air
Defrost setting
Meaning
Off
Temperature range in °C
Û
. Do not turn
25
