Product description
Product description
General product overview
* Example garage door illustration
1.
Drive head including LED module
3.
Rail (model example) drive side
4.
Carriage
7.
Rail connector (model example)
8.
Rail (model example) door side
9.
Tensioner
10. Wall bracket
Control elements
1
A
A1
A. Numerical display (A1 digital point)
C. OPEN / Start button
B. CLOSE button
D. Program button (PROG button)
1. Drive head
15. Hand transmitter
32
32
|
Manual / L-Door Efficiency 600
16
13
16
3
17
1
B
D
C
4
10
9
8
11
12
7
20
11. Door connector attachment
12. Linking bar
13. Central support
16. Support straps drive head
16. Support straps track
17. Mains cable, 1.2 m
20. Telescopic fitting for sectional doors (accessory)
15
*
W-600
