RAD 500:
Firmly slide the legs supplied over the front panel or the
second last fin, as illustrated.
RAD 1500 en RAD 2000:
Screw the 2 x 2 swivel castors with the 4 capped nuts onto the ends of the two wheel
supports. The wheels should be at the hollow side!
Turn the radiator upside-down (make sure you don't scratch the paint or the floor!)
Remove the wing nuts from the U-shaped bolts.
Then mount the U-shaped bolts left and right between the outer fins.
Slide the wheel supports with wheels over the ends of the U-shaped bolt, so that the
wheels are as far as possible mounted.
Now tighten the wing nuts tightly onto the ends of the U-shaped bolt, but not so tight as
to damage the oil-filled fins.
Return the heater to its upright position, wheels down.
Warning: only use the heater when it is in an upright position, with the wheels (or feet)
attached to the bottom (as pictured on the front of this manual). Any other position is
Select a suitable location for the device taking into account all the aforementioned
warnings in this manual.
Check that the socket used is earthed and that it matches the power specified on the
heater's type plate.
Set-up and operation
Set the ON/OFF switch to 0 (off) and the thermostat button to MAX.
Fully insert the plug into the socket. When doing so, completely unwind the flex. The
RAD 1500, 2000 and 2000T lamp will now light up.
dangerous!
43
