sage sequence, however, the audio file must first
be copied to the internal memory of the insertion
module (
☞
chapter 6 .6 .2) . To replay an audio file:
1) Press the button MENU (10) . The display will
show:
Mode Set
Time
2) Press the button UP (12) or DN (11) repeatedly
until
appears on the lower display
SD Card
line .
3) Press the button ENTER (6) . The display will
now show:
Choose
Play
If
Check SD Card
check if the card has been properly inserted
into the slot .
4) Press the button ENTER . The display will now
show:
PlayBack
Voice:01
5) Use the button UP or DN to select the
audio file to be replayed (
Voice:01 – Voice:20
6) Press the button START/ STOP (14) to start the
replay . During replay, the indication on the first
line of the display will change to
If the replay fails to start, there may be no
file with the selected name on the memory
card or the format or the size of the file may
not be correct .
6.6.2 Copying an audio file
To copy audio files to the memory of the insertion
module:
1) Press the button MENU (10) . The display will
show:
Mode Set
Time
2) Press the button UP (12) or DN (11) repeatedly
until
appears on the lower display
SD Card
line .
3) Press the button ENTER (6) . The display will
now show:
Choose
Play
If
Check SD Card
appears on the display,
M:1 – M:6
) .
Playing
appears on the display,
check if the card has been properly inserted
into the slot .
4) Use the button UP to select the option
on the lower line .
5) Press the button ENTER . The display will now
show:
Copy
Voice:01
6) Use the button UP or DN to select the file to be
copied (
M:1
7) Press the button ENTER .
pear on the display while the previous message
is being deleted from the storage . Then, the
display will show
progress of the copying process .
Then, if required, proceed in the same way to
copy further audio files (
To copy all suitable audio files from the mem-
ory card to the memory of the insertion module,
select the option
the button ENTER .
or
7 Specifications
Frequency range
MIC: � � � � � � � � � � � � � � � � 150 – 15 000 Hz
LINE: � � � � � � � � � � � � � � � 50 – 15 000 Hz
.
Audio input
Connection: � � � � � � � � � � 3�5 mm jack, unbalanced
Sensitivity, impedance
MIC: � � � � � � � � � � � � � � 2�5 mV, 600 Ω
LINE: � � � � � � � � � � � � � � 245 mV, 10 kΩ
Headphone output
Output power: � � � � � � � � 24 mW max� at 64 Ω
Minimum impedance: � � � 64 Ω
Storage capacity
"Voice01" – "Voice20": � � 20 × 128 kBytes (23 sec�*)
"M1" – "M6": � � � � � � � � 6 × 2176 kBytes (360 sec�*)
Power supply: � � � � � � � � � � ⎓ 15 – 17 V, 150 mA
Ambient temperature: � � � � 0 – 40 °C
Dimensions (W × H × D): � � 194 × 40 × 85 mm
Weight: � � � � � � � � � � � � � � � 270 g
Subject to technical modification .
All rights reserved by MONACOR
& Co. KG. No part of this instruction manual may be repro-
duced in any form or by any means for any commercial use.
–
/
–
M:6
Voice:01
will briefly ap-
ERASE
and indicate the
Copying
☞
step 6) .
in step 4 and press
Copy All
* for recordings via PA-1120DMT
INTERNATIONAL GmbH
®
Copy
) .
Voice:20
23
