Temperature
and humidity
detector
Power
Light indicator
Socket for the
micro-SD card
Reset
III. INSTALLING AND CONFIGURING THE VIDEO BABY MONITOR
a. Installing the camera
Plug the camera into the mains using the adapter supplied and place it at least 1 metre from your
baby's head and up to 2.5 metres from baby in order to enjoy good picture quality.
The camera is not equipped with a battery and must be kept plugged in in order to work.
1. You can twist the rod of the camera to place it or fasten it to different types of
supports. The camera must not under any circumstances be fastened to a cot with bars
or within baby's
2.
You can also fasten the camera to a number of surfaces (wall, partition, unit, etc.)
using the assembly support supplied (it can be fastened with the screws or the adhesive
strip).
Light indicator
Power supply port
Continuous red light: abnormal situation concerning the camera's network
Flashing red light: Wi-Fi connection pending, or currently connecting (faster
Flashing blue light: Wi-Fi confi guration pending, or currently connecting (faster
May contain a SD-card with a maximum storage capacity of 128 Gb.
Press the "Reset" button for 5 seconds to reset the appliance (if you have
modifi ed the settings, the default settings will be displayed again). Press for 1
second to activate the Wi-Fi connection in manual mode.
tail
Reset button
Loudspeaker
5V DC +/- 10%
fl ashing)
Continuous blue light: working normally
fl ashing)
Micro-SD card
connector
Microphone
11
