Auto
AUTOMATIC operating mode
• The transmitter follows the program (set in
according to the current time. By pressing OK and then
t and u , an exemption of the temperature can be set
until the programme's following change of cycle.
At the next cycle change,
Use + and - to set the desired temporary temperature.
At the next cycle change,
gram continues without changes.
You can always stop the exemption by pressing (
Holiday function
This function puts your heating system in FROST PROTEC-
TION mode
during the number of days of your choice.
• Using the t or u , keys, go to
t and u keys to select the number of days (d). Press
OK to confirm.
• The holiday period will begin when OK is pressed to
confirm (can be set to 1 to 44 days). Press OK to con-
firm: the
symbol blinks, and the number of days will
count down until the end of the period.
• Please note that a holiday period is defined in full days
(if it starts at 8:20, it will end at 9:00 at the end of the
number of days selected).
• Exit holiday mode at any time by pressing (
boost Function (available in modes
This function allows you to rapidly increase the tempera-
ture in your bathroom and/or dry your towels at a given
time for a defined period, without changing any of the
programmes.
• Electric or combined towel radiator: :
Press the Boost key: the
cate that the device is heating to maximum tempera-
ture. The Boost timer replaces the current time (the
factory default Boost time is 30 minutes). The "A" LED
blinks red.
To change the Boost duration, press OK and set using
the + and - keys: the setting is done in 10 minute steps
(min: 0:00 / max: 2 hrs).
To turn off the Boost function, press (
• Electric or combined towel radiator with Turbo
option:
Select the desired mode by pressing the Boost but-
ton repeatedly
: : (device only – F LED) /
only – E LED) /
(device + Turbo – F and E LEDs) /
_ _Stop.
The Boost timer replaces the current time display.
To change the Boost duration, press OK and set using
the + and - keys: the setting is done in 10 minute steps.
NOTE : You can stop the forced operation at any time
by pressing the Boost key until it disappears or by
pressing (
) .
Keypad lock
Use this feature to avoid changes to transmitter settings.
To lock the keypad, press and hold the (
press t or u .
The keypad lock symbol should appear.
Repeat the same procedure unlock the keypad.
4
) mode)
appears.
disappears and the pro-
)
.mode. Next, use the
) .
, Auto ,
,
,
)
segment appears to indi-
) .
(Turbo
) key, and then
Infrared Thermostat Transmitter with Digital Display - Instructions PPLIMP10314/Bd of 03/03/2011
User settings
You transmitter has a settings menu to allow you choose
different settings to suit your own preferences.
To access this menu, press and hold the (
seconds. The first parameter in the list below will be dis-
played.
You can now choose a setting using th t and u keys.
Once you have chosen the setting, press OK to access set-
tings (flashing display) and change using t and u. Press
OK again to confirm your setting.
To exit the user menu and return to the main menu, go to
the "End" setting and press OK.
• LANG : Choose the language (FrANçais/English)
• SOUF : Turbo control (yes/no)
• dEG :
emperature units
( °C: Celsius / °F: Fahrenheit)
• tEMP : Room temperature display (yes/no)
• Sond : Sensor used for temperature control:
Int = Room temperature sensor inside the
transmitter.
Ext = Sensor on the receiver (on the radiator)
The receiver/radiator sensor is the default sensor.
• C : calibration offset added to the order transmitted
to the receiver (-3.0°C to +3.0°C, by default set at
0.0°C)
Note : this value can only be adjusted if SENS=Ext.
If SEN=Int, this value is fixed at 0.0°C.
• Air.C : Calibration of room temperature sensor (sen-
sor on the transmitter).
Calibration must be done after a given order has
been operating for a day.
Place the thermometer in the middle of the room at
about 1.5 m above the floor. Record the tempera-
ture shown after 1 hour.
When you enter calibration mode for the first time,
the indicator says "no", which means no calibration
has been performed yet.
Enter the reading on your thermometer using the +
and - keys and confirm your settings with OK. YES
appears to indicate that calibration has been per-
formed.
Important note :
Un écart de température trop important peut signi-
fier aussi une mauvaise installation de votre émet-
teur.
• If the temperature difference is too great, this could
mean your transmitter was not installed properly.
• 24H/12H: unit of time 24H = 24:00 / 12H = 12:00
AM
• ChG.T: Automatic Daylight Saving Time adjustment
yes = the time will change automatically
no = the time must be changed manually
• CLr ALL : Resets to factory defaults. Also deletes the
time and U1/U2 programs.
Press and hold OK for 10 seconds to reset.
• End: Exit user menu
Press the OK key to exit the menu and return to the
main screen.
) key for 10
