6.3
Setting driving energy
Select the energy setting that suits the application. If no empirical values are available, always start with the
minimum driving energy. Increase driving energy step by step until the fastener is driven correctly.
For detailed information, request a copy of the Hilti 'Direct Fastening Technology Manual' or the
corresponding local Hilti 'Technical Guide to Fastening Technology' from your Hilti Store.
1. To increase power, turn the adjusting knob for driving energy in the + direction.
Energy levels:
•
1 = lowest energy
•
4 = highest energy
2. To reduce power, turn the adjusting knob for driving energy in the − direction.
3. Check whether the fastener was correctly driven in accordance with the operating instructions of the
fastener.
6.4
Driving fasteners
1. Hold the fastening tool perpendicular to the base material and press the fastening tool against the surface
until it is fully compressed (1).
2. Press the trigger to drive the fastener (2).
3. Cycle the fastening tool with the cycling grip (3).
6.5
Driving X-HVB fasteners for composite beams
The X-76-F-HVB fastener guide is needed for installing shear connectors for composite beam constructions.
1. Set the lever of the X-76-F-HVB fastener guide to position 1.
2. Insert a fastener.
3. Position a shear connector on the fastener guide (1).
4. Position the fastening tool.
5. Hold the fastening tool perpendicular to the base material and press the fastening tool against the surface
until it is fully compressed (1).
6. Press the trigger to drive the fastener (3).
7. Cycle the fastening tool with the cycling grip (4).
▶ Repeat the steps to secure another shear connector.
If you want to drive a second fastener in the same shear connector, set the lever of the X-76-F-
HVB fastener guide to position 2 and repeat the steps.
6.6
Unloading fastening tool
1. Cycle the fastening tool until the cartridge strip is visible at the discharge aperture.
2. Pull the cartridge strip out of the fastening tool.
3. Hold nail strip (1) and push the stopper to the rear (2).
4. Pull the nail strip out of the magazine (3).
7
Troubleshooting
WARNING
Risk of explosion! Cartridges may fire (explode) if handled improperly.
▶ Do not use force to remove cartridges from the fastening tool or the magazine strip.
WARNING
Hazard due to hot surfaces! The fastening tool can become hot in use.
▶ Wear protective gloves.
