ENGLISH
Typical applications
See Figures 1-6;
The images shown refer to typical applications for this
product.
In particular, in Figure 1, it is possible to check the
correct orientation of the product from duct:
A = intake
B = delivery
Installation
See Figures 7-10.
The images shown are purely indicative.
purpose is to illustrate the main assembly steps for the
entire range.
IMPORTANT: See the "Wiring Diagrams" paragraph to
check the 3 ventilation speeds.
IMPORTANT
If the aspirator is mounted at a height less than or
equal to 2.3 m from the floor, it is mandatory to install:
• the frame with external safety net (fig.6) or the
gravity shutter (fig.5);
• the internal fixed protective grid in case the
appliance is not intubated (fig.4).
Wiring diagrams
See Figure 11
Connection with the optional device upon request is
foreseen to check ventilation speeds (device not
supplied in packaging):
- 11A) Vortice 3-speed selector
Code 12866 o 12891
IMPORTANT
Vortice guarantees correct product operation and
control only when paired with the Vortice 3-speed
selector (Code 12.866-12891).
Other types of connection
Alternatively, other connection diagrams are available,
associated to different control modes (devices
provided by the installer).
Connection alternative for new installation
- 11B) max
- 11C) med
- 11D) min
Machine replacement on existing system
Connection without modifications to the electrical
system: the same switches as on the existing system
will be used.
Maintenance / Cleaning
Fig 12-14.
Important information
concerning the
environmentally compatible
disposal
Their
This product complies with Directive 2012/19/EU on
the management of waste electrical and electronic
equipment (WEEE).
The crossed-out wheeled bin symbol on the appliance
indicates that, at the end of its useful life, the product
must be taken to a specialised company for transport
and treatment. This company will take care of the
disposal of the various materials making up the
product and their subsequent proper
recycling.
Alternatively, the manufacturer of the
appliance is obliged to take back the
product to be disposed of in exchange for
the purchase of an equivalent appliance.
11
