UK
•
Unscrew the connection directly at the inlet nozzle only
•
Connect this pipe to the solar collector only and fasten this with a hose clip.
•
Attach the hose Ø 38 mm included to the outlet side of the solar collector and the other end to
your pool's inlet nozzle.
•
Turn the aluminium supporting poles to the vertical position, and adjust the poles to the
appropriate length.
•
Hold the end of aluminium pole, and turn it clockwise to lock the aluminium pole
•
Remove the protective covering on the upper side of the collector.
3.1.2 Connecting several collectors
If you would like to increase the heating power, you can connect several collectors together.
For this you will need a additional swimming pool hose Ø 38 mm. We recommend connecting a
maximum of 2 collectors, depending on the power of your filter unit.
We definitely recommend use of a bypass set. Not only does this help optimal control of heat
output, it also helps targeted control of the water flow rate, depending on the power of the filter unit.
4.
Initial use
Once the solar collector is assembled and the hoses are connected to the filter pump and the pool,
open the water supply and ensure that water is flowing through the hose. Then turn on the filter
system. Air bubbles will rise from the inlet nozzle in the pool. This happens as the air is expelled
from the solar collector. If this continues for more than 2-3 minutes, check the tightness of the
connections in your system.
Please note: Cover your pool overnight to avoid loss of heat.
5.
Trouble shooting
Problem
The pool does not warm up.
No bubbles appear after the
equipment has been attached to the
pump.
Air bubbles come out of the pool
return after the pump has been
turned on.
Water escaping.
MV-1923-08-2020 . © Alle rettigheder forbeholdes Swim & Fun Scandinavia ApS
Cause / Solution
•
Make sure that water is flowing through the hoses.
•
Has it been sunny enough?
•
Exploit the maximum amount of sunlight and increase the running time
of the filter pump.
•
Cover your pool overnight to avoid loss of heat.
•
It is possible that you may need several Solar Board Heaters.
•
Check the filter system and ensure that water from the pool is flowing
through the filter pump, then through the Solar Board Heater and finally
through the connector hose back to the pool.
•
Check the connector hoses for any
•
damage.
•
Check that the hose clamps have been properly tightened.
•
Check the seals in the system of pipes.
•
Check whether you have tightened the hose clamps tightly enough.
•
Check the connector hoses for any cracks.
15
