• Remove the screw of the hinge cover
plug (a) .
• Unscrew the upper hinge and remove it
(b).
• Unscrew the screw and remove the door
stopper (c).
a
• Remove the door.
• Remove using a tool the cover (e), un-
screw the lower hinge pivot (f) and place
it on the opposite side.
• Re-insert the cover (e) on the opposite
side.
• Re-insert the door .
• Pay attention that the front board of the
doors are parallel to the front board of
the top.
• Fix the door stopper on the opposite
side.
• Position and fix the upper hinge (that can
be found in the instruction for use bag)
on the opposite side .
d
d
b
c
• Fix the screw of the new cover hinge
(that can be found in the instruction for
use bag).
2
1
4
• Lift up the appliance to vertical position.
• Open the door and reposition the upper
door plastic trim with screws.
• Fix the handle on the opposite side, in-
sert the plastic plugs into the holes left
open that can be found in the instruction
for use bag.
Warning! Reposition, level the
appliance, wait for at least four hours
and then connect it to the power
socket.
In case you do not want to carry out the
above mentioned operations, contact the
nearest After Sales Service Force. The After
Sales Service specialist will carry out the re-
versibility of the doors at your cost.
electrolux 35
e
5
f
3
