5.2.2. Assembling the product
1. Carefully place the product on a soft, stable
and flat surface.
2. Remove the rubber protection plugs
the floor stand mounting holes
3. Place the first floor stand
and align the holes on the floor stand with
6
the mounting holes
4. Attach the first floor stand
r
with the bolts
using a screwdriver.
5. Perform step 3. and 4. for the second floor
stand.
6. Put the product in an upright position on the
floor.
- The product is now ready to use.
5
from
6
.
q
on the product
.
q
to the product
5.2.3. Mounting the mounting bracket
NOTICE
• Never mount the product on the wall with the
floor stands placed on the product.
• Take a minimal spacing into account when
mounting the mounting bracket. See the next
image.
820
20
435
350
465
1. Determine the desired position of the
e
mounting bracket
of the mounting bracket accordingly.
2. Drill a hole with a diameter of 6 mm at each
of the 4 marks.
u
3. Place a plug
into each of the drilled holes
and use a hammer to fix the plug.
435
mm
and mark the 4 holes
15
