GB
Instructions for use
Portable double burner gas stove
!
DANGER
Do not use a pan larger than L680 x W340mm as can cover the gas cartridge
compartment and cause the gas cartridge to overheat.
EXPLOSION HAZARD:
fig. 1
1
fig. 6
Body case
Pan support
Burner
1
3
5
2
Cartridge cover
4
Drip pan
Cartridge lever
6
Ignition electrode
Gas passage release lever
9
11
10
Thermocouple
fig. 3
fig. 4
900060508
>50cm
5
2
9 10
6
8
Notch in cartridge collar
7
11
Valve guide
fig. 2
Control panel
7
High / low control knob with piezo-ignition
8
fig. 5
INSTRUCTIONS FOR USE
IMPORTANT
- Read the instruction carefully before use to familiarize yourself with the appliance before conneting
it to its gas cartridge.
- Keep these instruction for future reference.
- This appliance shall only be used with SNN-29 butane cartridge. It may be hazardous to attempt to
fit other types of gas containers.
- Don't use appliances when ambient temperature is higher than 35℃.
- Don't use appliances when the cover of cartridge enclosure is in open position.
- Release or disconnect the gas cartridge after every use.
- One of two gas cartridges must be removed from the cartridge compartment while only one burner
is turned on.
- This appliance should only be used in well-ventilated areas (2m /h/kW min.) away from inflammable
materials.
- Keep young children away from the appliance.
WARNING
Check that seals (between the appliance and the gas cartridge) are in place and in good condition
before connecting the gas cartridge (fig.6).
Don't use the appliance if it has damaged or worn seals.
SAFETY DEVICE
- The appliance is equipped with a safety device which stops the flow of
gas if the pressure in the cartridge, e.g. because of overheating, becomes too high.
To continue usage...
- Turn the control knob to "●" position.
- Turn the cartridge lever to "UNLOCK" position and take the cartridge out.
- Turn the control knob to the ignition position to release any excess pressure inside the valve.
- Push down the reset lever with red rubber cap.
- Place new cartridge after checking that the cartridge lever is in "UNLOCK" position. ( If new cartridge
is not hand, cool down the cartridge in use with water. )
- The cartridge can only be installed when the control knob is in the OFF-position.
USING THE STOVE FOR THE FIRST TIME
1. Check that the control knob (8) is set to position "●" by turning it clockwise and the cartridge lever
(6) is set to UNLOCK.
2. Open the cartridge cover (2) and insert the cartridge, with the head to the front, so the notch points
upwards and aligns in the value guide (fig.2).
3. Press the cartridge lever (6) down (fig.3) and close the cartridge cover.
4. If you hear a "hissing" noise, the cartridge has not been correctly fitted. Do not attempt to ignite the
appliance but move lever (6) to the "Unlock" position and repeat step (1-4).
5. Push down the gas passage release lever (11), then push and turn the control /ignition knob (8) fully
to the ignition position "
" until it clicks.(fig.4) Hold the gas passage release lever in this position for
a few seconds to prime the flame guard thermocouple. Repeat this action until burner ignites.
