OVERVIEW
This Operation Manual aims to familiarize you with the technical data, design, rules of
operation and storage of the Aiwa AVC-630 domestic electric vacuum cleaner, model
(hereinafter, the vacuum cleaner, device).
NOTE: The illustrations provided in this Operating Manual are general schematic
images only.
UNPACKING THE DEVICE AND PREPARING FOR OPERATION
1.
Opening the Package: Carefully open the package on a flat, stable surface.
2.
Remove the polystyrene: Remove the polystyrene that protects the vacuum.
3.
Remove Accessories: Remove all built-in accessories and materials.
4.
Remove the Vacuum: Lift the vacuum out of the box.
5.
Remove the Plastic Bag: Remove the protective plastic bag from the vacuum.
6.
Save the Packaging: Save the outer packaging for future transports.
Follow these steps to ensure that your vacuum cleaner and accessories are safely
unpacked and ready for use.
VACUUM ASSEMBLY:
ATTENTION! The components of the vacuum cleaner are made of plastic
and carefully assembled together. To avoid damaging the latches and
pull-out buttons, do not exert force during assembly. Make sure the parts
are installed on the pull-out buttons without warping and are firmly in place with
the latches.
PIPE INSTALLATION
1.
Insert the tube: Place the tube in the main unit until you hear a click. (IMAGE
1A)
2.
Uninstalling the Tube: To remove the tube, press the release button and pull it
out. (IMAGE 1B)
INSTALLING THE SUCTION BASE
1.
Attach the Suction Base: Insert the suction base into the end of the tube until
you hear a click. (IMAGE 1C)
2.
Uninstalling the Suction Base: To remove the suction base, press the release
button and remove it. (IMAGE 1D)
BATTERY INSTALLATION
1.
Install the Battery: Place the battery on the bottom of the main unit until it
clicks into place. (IMAGE 2A)
2.
Uninstalling the Battery: To remove the battery, press the release button and
remove it. (IMAGE 2B)
WALL BRACKET
1.
Install the Wall Bracket: Place the bracket on the wall and mark the points
where the holes will be drilled. Make sure the suction base touches the ground
so that the stand doesn't support the full weight of the vacuum. (with a height
of approximately 95 cm from the bottom of the charging dock to the floor)
2.
Attach the Stand: Drill the holes and secure the bracket with expansion
screws to hang the vacuum cleaner. Note: Do not fix it on damp walls such as
the kitchen.(IMAGE 4: A-Load Carrier B-Expansion Plug C-Screw)
ENGLISH
