Product description
Overview
1
Inlet 1 (suction side)
• Filter casing for pond bottom filtration
2
Inlet 2 (suction side)
• Connection of a satellite filter or skimmer.
• The flow rate on inlet 2 and with it the intake ratio of inlet 1 and 2 is adjustable. To do so, undo
the locking mechanism and push the connection to one of the following positions:
− Position 0: Inlet 2 is closed, intake only via inlet 1.
− Position 1/2/3: Inlet 2 is opened by approx. 25/50/75 %; this means intake via inlet 1 and 2
based on the set intake ratio.
− Position 4: Inlet 1 is closed, intake only via inlet 2.
3
Outlet (pressure side)
• Connection of the return flow to the pond (e.g. via a water course).
4
Switching power pack with power plug
• Pump power supply
5
House sleeve for outlet (recommendation).
6
Stepped hose adapter for inlet 2 and outlet (alternative).
7
Cover cap for closing inlet 2 when it is not in use.
8
Hose clips for fastening hoses on the hose sleeves.
9
Rubber feet for pump holder for dry installation.
22
AMX0139
