SETUP
Position the WT460A in such a way that the best possible reception is available to the device. While still having the WT460A
switched off, connect the device to the mains supply via the supplied power lead.
To achieve the best reception for both BT streaming - and WiFi signals, make sure to install the antennas.
When using an external playback device, connect this to the AUX input RCA sockets on the rear panel of the WT460A.
The WT460A has 2 separate amplifiers (CH 1 and CH2), both having left and right output sockets located within the speaker
output terminal (binding post).
NOTE: the minimum impedance load per channel is 4 Ohms.
OPERATION
When all connections are made correctly: turn on the power of WT460A, the power LED will be illuminated.
Choose the correct input mode by pressing INPUT / WPS / RESET.
Normally, playback will start automatically when an SD card or a USB stick is inserted in their corresponding slot. If not, select
USB or SD by pressing INPUT / WPS / RESET to initiate the respective mode manually. Press PLAY / PAUSE to start playback.
For all modes: press PREVIOUS / VOLUME – or NEXT / VOLUME + to change tracks. Press and hold the same buttons to
decrease or increase volume respectively.
Factory reset: press and hold INPUT / WPS / RESET for 5 seconds to initiate factory reset. The device will be returned to
factory settings.
REMOTE CONTROL
1. POWER ON/OFF
Press to turn the device on/off.
2. MUTE
Press to (un)mute the device.
3. VOLUME
Press to decrease or increase the volume level.
4. PREVIOUS/NEXT
Press to change to previous- or skip to next track.
5. PLAY/PAUSE
Press to start/resume or pause play.
6. BASS
Press to increase or decrease bass level.
7. TREBLE
Press to increase or decrease treble level.
8. SOURCE
Press to change input mode.
DOWNLOAD AND INSTALL WIIM LEGACY PLAYER APP
Download the latest version of the LEGACY Player app via Apple store or Google play. Here you will also find the latest features
and explanations on how to use them.
Legacy Player Apple Store
Legacy Player Google Play
5
