1
What's in the box
Note:
–
For more information, please download the owner's
manual from www.jbl.com
2
Overview
2.1 Top panel
7
6
5
1)
•
Battery level indicator.
2)
•
Press to power on or off.
CH_JBL_PartyBox_100_QSG_SOP_V12.indd 1
3)
•
Press to enter Bluetooth pairing mode.
•
Press and hold for 20 seconds to forget all
paired devices.
4)
•
Press to toggle between different light patterns.
•
Press and hold for 2 seconds to turn the strobe
light on or off.
5)
•
Press repeatedly to switch between bass boost
level 1 and level 2 or turn off.
6)
/
•
Press to increase or decrease the volume level.
•
Press both simultaneously to mute the audio
output.
7)
•
Press to play or pause the music.
2.2 Back Panel
1
2
3
1)
USB
•
Charge an external USB device.
•
Connect to a USB storage device
2)
AUX
•
Connect to an external audio device through an
audio cable.
3)
VOLUME (MIC)
•
Rotate the knob to adjust the microphone
1
volume.
2
4)
MIC
•
Connect to a microphone (not provided).
3
5)
VOLUME (GUITAR)
4
•
Rotate the knob to adjust the guitar volume.
6)
GUITAR
•
Connect to a guitar (not provided).
7)
GAIN
•
Guitar and microphone gain control buttons to
match different sensitivity of the mic and guitar.
EN
7
6
5
4
1
5/10/2019 4:49:15 PM
