16.1 Appliance diagram

1 Control Panel
2 Connector for vacuum hose
3 Sealing profile (which presses the bag against the sealing bar)
4 Lower gasket + 5 Upper gasket
6 Sealing bar:
seal but not to stick to the strip. Place the bag over this sealing element.
WARNING
Please observe the following safety notice to reduce the risk of burns.
► Never touch the sealing bar while the unit is operating.
► Do not remove the Teflon tape (T).
7 Vacuum chamber (with removable liquid tank)
8 Air intake: Air intake connects with vacuum chamber and pump.
9 Vacuum hose for example for vacuuming of canisters and wine stoppers
10 handle: Close the lid and press down the handle firmly until the first progress LED
lights up.
Contains a heating wire covered with teflon which allows the bag to
Please note
