Important! The fitting must be installed, flushed
and tested after the valid norms!
Operation
The mixer is activated by lifting the lever handle.
Turning to the left = warmer water,
turning to the right = cooler water.
32420000: The flow is changed from bath to
shower function by pulling the knob at the upper
side of the spout. After shutting off the water
flow, the mixer returns automatically to the bath
function.
Technical Data
Operating pressure:
Recommended operating pressure:
MPa
Test pressure:
(1 MPa = 10 bars = 147 PSI)
Hot water temperature:
Recommended hot water temp.:
Rate of flow:
anti-pollution function
Test certificate
DVGW
31751000
31752000
English
max 1 MPa
0,1 – 0,5
1,6 MPa
max 80° C
65° C
ca. 22 l/min 0,3 MPa
P-IX
SVGW
To adjust the hot water limiter on single lever
mixers, please see page _1b.
No adjustment is necessary when using a
continuous flow water heater.
Hansgrohe single lever mixers can be used
together with hydraulically and thermically
controlled continuous flow heaters if the flow
pressure is at least 0,15 MPa.
Spare parts see page 3
1
handle
2
screw cover
3
flange
4
nut
5
cartridge cpl.
6
aerator cpl.
7
selector assy
8
diverter knob
9
non return valve
10
connection hose
11
fixing set
12
seal
ACS
NF
X
X
31791000
96338000
94192000
94194000
92730000
96512000
94077000
94078000
94074000
96507000
96016000
97608000
WRAS
KIWA
5
