ENGLISH
3. ASSEMBLY
Fig. 2
Assembling the vacuuming tube and the motorised brush
To install the motorised brush into the vacuuming tube, align both making sure the tab on
-
the motorised brush matches the guides on the tube, and introduce one into the other until
they are firmly fixed.
To disassemble them, press the motorised-brush release button, and pull from the
-
vacuuming tube while you hold the vacuuming brush head.
Installing the tube, motorised brush, and main body
To complete the installation of the upright vacuum cleaner, hold the vacuuming tube in an
-
upright position and insert it into the main body.
To remove the vacuuming tube, press the vacuuming-tube release button and pull the
-
vacuuming tube while firmly holding the main body . Fig. 3
4. OPERATION
You can use this vacuum cleaner in two different manners:
-
Handheld vacuum cleaner, attaching the accessories directly to the main body.
-
Upright vacuum cleaner, using the vacuuming tube with the accessories assembled.
Using the vacuum cleaner
1.
Plug in the vacuum cleaner.
Turn on the vacuum cleaner by pressing the power button.
2.
3.
Move it back and forth for cleaning.
Warning:
The motorised brush operates at a very high speed to prevent damage to the cleaning
-
surface. Do not stay on the same spot for longer than necessary.
-
If the brush gets blocked during operation, the brush stops spinning automatically to
prevent tangles and possible damage. Turn off the vacuum cleaner; release and clean the
brush. Do not use the vacuum cleaner until it has cooled down.
2-in-1 narrow accessory for corners and furniture
This accessory is preferably used with the handheld vacuum cleaner and allows cleaning
furniture without damaging it and reaching harder-to-reach dirt in corners. You can also use
this accessory with the vacuuming tube. Fig. 4
CONGA POPSTAR 600 VITAL
28
5. CLEANING AND MAINTENANCE
Turn the appliance off, unplug it from the power socket, and allow it to cool down before
-
cleaning it.
Use a soft, slightly dampened cloth to clean the device's surface.
-
Never immerse the device in water or other liquids, nor allow liquids to enter the device.
-
Do not use abrasive cleaners or scouring pads to clean the product.
-
Do not leave the device in a place with direct sunlight.
-
-
Do not leave the device in a wet place after cleaning it.
-
After the brush has been used for a long time, bristles might start to tangle with hair and
other particles. Clean it for it to operate correctly again.
Filters and tank cleaning
To avoid the appliance from overheating and losing suction power, it is suggested to clean
-
the filters frequently. To make the most of the suction power, it is suggested to clean the
filter after every use.
The filers' shelf life will depend on usage frequency and the type of particles which are
-
frequently vacuumed. It is recommended to replace the filters approximately every 6
months.
Turn the vacuum cleaner off and unplug it from the power supply.
1.
2.
Press the dust-tank release button as shown in Figure 5.
3.
Gently remove the dust tank from the main body and empty the dirt into a waste bin. Fig. 6
Remove the filtering system and separate its parts for cleaning. Fig. 7
4.
After cleaning, replace the filtering system and put the dirt tank back into place. Fig. 8
5.
Vacuum and shake the filters to remove every particle and dust remain that may block
-
them and difficult the correct air circulation. Remember not to use the vacuum cleaner
without the filters properly assembled.
-
Filters cannot be washed inside a washing machine or dried with a hair dryer.
Do not brush the high-efficiency filter.
-
Motorised-brush release Fig. 9
This vacuum cleaner has a protection feature that can cut off the power supply to the motorised
brush and stop its operation when the air duct and/or the brush get blocked. Switch off the
vacuum cleaner and unblock the brush or air duct immediately.
Once unblocked, do not use the product until it cools down.
1.
Unplug the vacuum cleaner from the mains and press the motorised-brush release
button to remove it.
Turn the knob on the bottom of the motorised brush with a coin to put it in the unlocked
2.
position, as shown in Figure 9.
3.
Open the latch
ENGLISH
CONGA POPSTAR 600 VITAL
29
