7
Control system connection
• The control unit OASE Eco Control (accessories) is required to operate the pump.
• Alternatively, the pump can be integrated in an OASE Control network.
Hose sleeve ∅ 50 mm
• For information on OASE control, visit www.oase.com.
Hose sleeve ∅ 38 mm
8
9
10
Hose clips for fastening hoses on the hose sleeves.
Symbols on the unit
Installation variants
• Variant (a): Submerged pump installation
– The pump is positioned in the pond or basin.
– Water flow via the filter cage.
• Variant (b): Dry pump installation
– The pump is installed without the filter cage outside of the pond or basin but lower than the
water level.
– Water flow via a satellite filter or skimmer.
The unit is dust-proof and water-tight down to 4 m.
Possible hazard for persons wearing pace makers.
Only operate the unit with a safety transformer.
Protect the unit from direct sunlight.
Never dispose of the unit with normal household waste.
Read the operating instructions.
EN
AMX0157
23
